Deskripsi Produk
LCD PROYEKTOR BENQ MX-528 ( XGA 3300 LUMENS ) HDMI
Semua Spesifikasi
Display Projection System DLP
Resolution XGA, 1024x768
Brightness (ANSI lumens) 3300
Contrast Ratio (FOFO) 13000:1
Display Color 30 Bits (1,07 billion colors)
Native Aspect Ratio Native 4:3 (5 aspect ratio selectable)
Light Source Lamp
Light Source life* Normal 4500 hr Economic 6000 hr
SmartEco 6500 hr LampSave 10000hr
Resolution Support VGA(640 x 480) to WUXGA_RB(1920 x 1200)
*RB-Reduced Blanking
Light Source Wattage 196W
Optical Throw Ratio 1.96~2.15, (78"@3.1m)
Zoom Ratio 1.1X
Clear Image Size (Diagonal) 60"~180"
Projection Offset** 120%±5%
Image Size 30"~300"
Lens F = 2.56 ~ 2.68 f = 22.04 ~ 24.14 mm
Keystone Adjustment 1D, Vertical +/- 40 degrees
Horizontal Frequency 15K~102KHz
Vertical Scan Rate 23~120Hz
Audio Speaker 2W x 1
Interface PC (D-sub) 2
Monitor out (D-sub 15pin) 1
S-Video in (Mini DIN 4pin) 1
Composite Video in (RCA) 1
HDMI 1 (1.4a)
USB Type Mini B 1 (Download & Page up/down)
Audio in (3.5mm Mini Jack) 1
Audio out (3.5mm Mini Jack)1
RS232 (DB-9pin) 1
IR Receiver 1 (Front)
Security Bar 1
Compatibility HDTV Compatibility 480i, 480p, 576i, 567p, 720p, 1080i, 1080p
Video Compatibility NTSC, PAL, SECAM
Environment
Power Supply AC 100 to 240 V, 50/60 Hz
Typical Power Consumption 270W(Normal)
Standby Power Consumption <0.5W
Acoustic Noise (Typ./Eco.) 33/28 dBA
Operating Temperature 0~40℃
Accessories (Standard)
Carton
Brown carton, Hand carry type
Remote Control w/ Battery 1 (RCX012)
Power Cord (by region) Yes
User Manual CD Yes
Quick Start Guide Yes
Warranty Card (by region) Yes
VGA(D-sub 15pin) Cable Yes
